TWR A-Series
12-15W, Triple Output DC-DC Converters
TWR-5/1500-15/250-D48A Radiated Emissions
FCC Part 15 Class B 3 Meters
+12 / 15V
5
+
8 0
Converter Output = +5Vdc @ 1.35A and ±15Vdc @ 225mA
C IN
+
1
+INP U T
+5V
6
7
C O U T
+
C O U T
7 0
6 0
5 0
FCC C lass B Limit
2
–INP U T
COMMON
8
+
C O U T
40
30
–12 / 15V
2 0
1 0
0
Figure 2. Using External Capacitors
to Reduce Input/Output Ripple/Noise
–1 0
–2 0
1 00
Radiated Emissions
1 000
Frequency (MHz)
Input Fusing
Certain applications and/or safety agencies may require the installation of
fuses at the inputs of power conversion components. For Murata Power
Solutions A-Series TWR 12-15 Watt DC-DC Converters, you should use
slow-blow type fuses with values no greater than 2A.
8 0
TWR-5/1500-15/250-D48A Radiated Emissions
EN55022 Class B 10 Meters
Converter Output = +5Vdc @ 1.35A and ±15Vdc @ 225mA
C U S T O M
C A P A B I L I T I E S
7 0
6 0
Murata Power Solutions’ world-class design, development and manu-
facturing team stands ready to work with you to deliver the exact power
converter you need for your demanding, large volume, OEM applications.
And . . . we’ll do it on time and within budget!
Our experienced applications and design staffs; quick-turn prototype
capability; highly automated, SMT assembly facilities; and in-line SPC
quality-control techniques combine to give us the unique ability to design
and deliver any quantity of power converters to the highest standards of
5 0
40
30
2 0
1 0
0
–1 0
EN 55 0 22 C l ass B Limit
R adiated E missions
quality and reliability.
–2 0
We have compiled a large library of DC-DC designs that are currently used
in a variety of telecom, medical, computer, railway, aerospace and indus-
1 00
Frequency (MHz)
1 000
trial applications. We may already have the converter you need.
Contact us. Our goal is to provide you the highest-quality, most cost-
effective power converters available.
EMI RADIATED EMISSIONS
If you’re designing with EMC in mind, please note that all of Murata Power
Solutions’ TWR A-Series 12-15 Watt DC-DC Converters have been charac-
terized for radiated and conducted emissions in our new EMI/EMC labora-
tory. Testing is conducted in an EMCO 5305 GTEM test cell utilizing EMCO
automated EMC test software. Radiated emissions are tested to the limits
of FCC Part 15, Class B and CISPR 22 (EN 55022), Class B. Correlation to
other speci?cations can be supplied upon request. Radiated emissions
plots to FCC and CISPR 22 for model TWR-5/1500-15/250-D48A appear
below. Published EMC test reports are available for each model number.
Contact Murata Power Solutions’ Applications Engineering Department for
more details.
?
? Quality and Reliability
The A-Series are the ?rst DC-DC Converters to emerge from Murata Power
Solutions’ new, company-wide approach to designing and manufacturing
the most reliable power converters available. The ?ve-pronged program
draws our Quality Assurance function into all aspects of new-product
design, development, characterization, quali?cation and manufacturing.
Design for Reliability
Design for Reliability is woven throughout our multi-phased, new-product-
development process. Design-for-reliability practices are fully documented
and begin early in the new-product development cycle with the following
goals:
1. To work from an approved components/vendors list ensuring the use of
reliable components and the rigorous quali?cation of new components.
2. To design with safety margins by adhering to a strict set of derating
guidelines and performing theoretical worst-case analyses.
3. To locate potential design weaknesses early in the product-development
www.murata-ps.com/support
MDC_TWR12-15.C02 Page 4 of 5
